JXFM110
hammer type whirlwind mill is an stable and endurable crushing
instrument that has a beautiful appearance, compact structure, easy
operation.
Features:
·The
built-in temperature protector in the motor can stop the motor
automatically once the motor temperature is higher than set value; when
the temperature becomes normal, the motor can start again;
·The instrument can be matched with an auto feeder,
which can control the feeding speed of sample with high moisture or
grains with husks and improve crushing effect.
·The application scope includes gluten quantity and quality, grain viscosity, wheat falling number, etc.
Technical specification
Working power
|
AC220±10V 50Hz
|
Motor power
|
750W
|
Working chamber dia.
|
110mm
|
Hammer speed
|
16800r/min
|
Sieve pore dia.
|
0.5, 0.8, 1.5mm
|
Dimension
|
530mm×530mm×650mm
|
Total weight
|
51kg
|
