Unit Machine
Screw Conveyor
• It is mainly used for the level or gradient conveying of stock. Screw conveyor’ s ambient temperature is -20〜50℃; stock temperature is below 200 °C; gradient:β≤20°. The conveying length is generally shorter than 40 meters, maximally 70 meters.
• Made of high grade carbon Steel.
• With reducer.
• With anti-block system to ensure work safety.
|
Model |
Diameter of screw (mm) |
Pitch (mm) |
Rotating speed (r/min) |
Capacity (t/h) |
|
|
wheat |
flour |
||||
|
HSSL16 |
160 |
160 |
60-160 |
2.5-6 |
0.8-2.0 |
|
HSSL20 |
200 |
200 |
60-140 |
2.5-6 |
0.8-2.0 |
|
HSSL25 |
250 |
250 |
60-120 |
2.5-6 |
0.8-2.0 |
|
HSSL 32 |
320 |
320 |
60-110 |
2.5-6 |
0.8-2.0 |
|
HSSL40 |
400 |
350 |
60-100 |
2.5-6 |
0.8-2.0 |
|
HSSL50 |
500 |
400 |
60-80 |
2.5-6 |
0.8-2.0 |
