Unit Machine
Plansifter
• It is an important equipment in flour processing. Plansifter is mainly used for grading and inspecting of stocks from various systems in flour grinding
• Unique labyrinth sealing device at motor shaft end disallows flour's entry.
• At the bottom of main shaft, there is elastic supporting device for the balance iron.
• Drive shaft adopts imported self-aligning roller bearing which ensures precise concentric rotation.
• Top sieve frame adopts adjustable pressing mechanism, convenient and easy for operation.
• New type sieve frames and novel design of bins increase the sieving area and capacity.
• Doors and passages are rigorously sealed, no stock escape and leakage.
• Plansifter frame is made by bending and welding with steel plates which are used for automobile crossbeams. It has good rigidity and fatigue resistance.
• The whole machine is fully enclosed and the motor is built in, with elegant appearance.
|
Model |
HFSG 4×24H |
HFSG 6×24H |
HFSG 8×24H |
|
Sieve frame size (mm) |
740×740 |
740×740 |
740×740 |
|
Bin quantity |
4 |
6 |
8 |
|
Sieve frame quantity |
18-28 |
18-28 |
18-28 |
|
Sieve area (m2) |
30.4-53.4 |
45.6-80.1 |
60.8-106.8 |
|
Rotating speed (r/min) |
240 |
240 |
240 |
|
Swing diameter (mm) |
60-65 |
60-65 |
60-65 |
|
Power(kw) |
5.5 |
7.5 |
11 |
|
Installation height (mm) |
3700-4000 |
3700-4000 |
3700-4000 |
|
Effective sieve frame height (mm) |
2100 |
2100 |
2100 |
|
Weight (kg) |
3500 |
4900 |
6600 |
|
Dimension (mm) |
2032×2737×3700 |
2910×2737×3700 |
3776×2737×3700 |
